Forgejo on K3S

Forgejo is a lightweight, self-hosted Git service — a community fork of Gitea. In this post I’ll walk through how I deployed it on my home k3s cluster backed by a CloudNativePG (CNPG) PostgreSQL database, MinIO S3-compatible object storage for backups, and exposed it via Cilium’s Gateway API with automatic TLS through cert-manager.

Architecture Overview

The setup involves three main layers:

App layer — the Forgejo deployment, services, and ingress (Gateway + HTTPRoute)
Database layer — a CloudNativePG PostgreSQL cluster with WAL archiving to MinIO
Secrets layer — External Secrets Operator pulling credentials from Vault

Here’s the directory structure I’m using in my GitOps repo:

apps/
  base/forgejo/          # Forgejo deployment, services, config
  athena/forgejo/        # Cluster-specific overlays (gateway, TLS, routes)
databases/
  base/forgejo/          # CNPG cluster, backup schedule, object store

Prerequisites

You’ll need the following operators/controllers running in your cluster:

CloudNativePG for the Postgres cluster
Barman Cloud plugin for CNPG for WAL archiving and backups
External Secrets Operator for pulling secrets from Vault (or adapt this to your secret management of choice)
cert-manager for TLS certificate provisioning
Cilium as the CNI with Gateway API support enabled
A MinIO instance (or any S3-compatible store) for database backups

Step 1: Namespace

Everything lives in the forgejo namespace. Create it first with appropriate pod security settings:

# databases/base/forgejo/namespace.yaml
apiVersion: v1
kind: Namespace
metadata:
  name: forgejo
  labels:
    app.kubernetes.io/component: monitoring
    pod-security.kubernetes.io/enforce: baseline

Step 2: Database Setup

Secrets

The CNPG cluster needs database credentials. I store these in Vault and pull them using External Secrets Operator. The secret type must be kubernetes.io/basic-auth for CNPG to recognize it.

# databases/base/forgejo/forgejo-db-credentials.yaml
apiVersion: external-secrets.io/v1
kind: ExternalSecret
metadata:
  name: forgejo-db-credentials
  namespace: forgejo
spec:
  refreshInterval: "15s"
  secretStoreRef:
    name: vault-backend-global
    kind: ClusterSecretStore
  target:
    name: forgejo-db-credentials
    creationPolicy: Owner
    template:
      type: kubernetes.io/basic-auth
  data:
    - secretKey: username
      remoteRef:
        key: forgejo-secrets/forgejo-db-credentials
        property: username
    - secretKey: password
      remoteRef:
        key: forgejo-secrets/forgejo-db-credentials
        property: password

MinIO Secret for Backups

# databases/base/forgejo/minio-secret.yaml
apiVersion: external-secrets.io/v1
kind: ExternalSecret
metadata:
  name: minio-s3
  namespace: forgejo
spec:
  refreshInterval: "15s"
  secretStoreRef:
    name: vault-backend-global
    kind: ClusterSecretStore
  target:
    name: minio-s3
    creationPolicy: Owner
  data:
    - secretKey: ACCESS_KEY_ID
      remoteRef:
        key: minio-s3
        property: ACCESS_KEY_ID
    - secretKey: ACCESS_SECRET_KEY
      remoteRef:
        key: minio-s3
        property: ACCESS_SECRET_KEY

Object Store for WAL Archiving

This tells CNPG where to send WAL archives and base backups:

# databases/base/forgejo/minio-s3-objectstore.yaml
apiVersion: barmancloud.cnpg.io/v1
kind: ObjectStore
metadata:
  name: forgejo-objectstore
  namespace: forgejo
spec:
  configuration:
    destinationPath: "s3://backups/"
    endpointURL: "http://atlas.uclab8.net:9000"
    s3Credentials:
      accessKeyId:
        name: minio-s3
        key: ACCESS_KEY_ID
      secretAccessKey:
        name: minio-s3
        key: ACCESS_SECRET_KEY
    wal:
      compression: gzip
  retentionPolicy: 7d

PostgreSQL Cluster

A two-instance CNPG cluster with WAL archiving via the barman-cloud plugin and a Pod Monitor for Prometheus scraping:

# databases/base/forgejo/db.yaml
apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: forgejo-db
spec:
  instances: 2
  bootstrap:
    initdb:
      database: forgejodb
      owner: forgejo
      secret:
        name: forgejo-db-credentials
  storage:
    size: 1Gi
  plugins:
    - name: barman-cloud.cloudnative-pg.io
      isWALArchiver: true
      parameters:
        barmanObjectName: forgejo-objectstore
  monitoring:
    enablePodMonitor: true

Tip for recovery: The commented-out bootstrap.recovery block in the YAML is your escape hatch if you ever need to restore from a backup. Swap the initdb block for a recovery block pointing to your ObjectStore and you’re good to go.

Scheduled Backups

Take a full base backup every night at 3 AM:

# databases/base/forgejo/backup.yaml
apiVersion: postgresql.cnpg.io/v1
kind: ScheduledBackup
metadata:
  name: forgejo-db-backup
spec:
  schedule: "0 0 3 * * *"
  backupOwnerReference: cluster
  cluster:
    name: forgejo-db
  method: plugin
  pluginConfiguration:
    name: barman-cloud.cloudnative-pg.io

Database Kustomization

# databases/base/forgejo/kustomization.yaml
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
resources:
  - namespace.yaml
  - minio-secret.yaml
  - minio-s3-objectstore.yaml
  - forgejo-db-credentials.yaml
  - db.yaml
  - backup.yaml

Step 3: Forgejo App

ConfigMap

Forgejo is configured entirely through environment variables using the FORGEJO__section__KEY convention. This maps directly to sections in app.ini:

# apps/base/forgejo/configmap.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: forgejo-config
  namespace: forgejo
data:
  FORGEJO__actions__DEFAULT_ACTIONS_URL: https://data.forgejo.org
  FORGEJO__actions__ENABLED: "true"
  FORGEJO__attachment__PATH: /data/app/attachments
  FORGEJO__database__DB_TYPE: postgres
  FORGEJO__database__HOST: forgejo-db-rw:5432
  FORGEJO__database__NAME: forgejodb
  FORGEJO__database__SSL_MODE: disable
  FORGEJO__lfs__PATH: /data/lfs
  FORGEJO__log__ROOT_PATH: /data/app/log
  FORGEJO__picture__AVATAR_UPLOAD_PATH: /data/app/avatars
  FORGEJO__picture__REPOSITORY_AVATAR_UPLOAD_PATH: /data/app/repo-avatars
  FORGEJO__repository__ROOT: /data/git
  FORGEJO__security__INSTALL_LOCK: "true"
  FORGEJO__server__APP_DATA_PATH: /data/app
  FORGEJO__server__DOMAIN: forgejo.uclab.dev
  FORGEJO__server__HTTP_PORT: "3000"
  FORGEJO__server__PER_WRITE_PER_KB_TIMEOUT: "-1"
  FORGEJO__server__PER_WRITE_TIMEOUT: "-1"
  FORGEJO__server__ROOT_URL: https://forgejo.uclab.dev/
  FORGEJO__server__SSH_DOMAIN: git.uclab.dev
  FORGEJO__server__SSH_LISTEN_PORT: "2222"
  FORGEJO__server__SSH_PORT: "2222"
  FORGEJO__session__PROVIDER_CONFIG: /data/app/sessions
  FORGEJO__migrations__ALLOW_LOCALNETWORKS: "true"
  FORGEJO__migrations__ALLOWED_DOMAINS: "*.uclab8.net"

A few things worth calling out:

FORGEJO__database__HOST: forgejo-db-rw:5432 — CNPG creates a forgejo-db-rw service pointing to the primary instance automatically.
FORGEJO__security__INSTALL_LOCK: "true" — skip the web installer on first boot.
The write timeout settings of -1 are useful if you’re pushing large repos over slow connections.

Database Secret (App Side)

The app needs the DB credentials as well, but in a different format (raw env vars rather than basic-auth):

# apps/base/forgejo/secret.yaml
apiVersion: external-secrets.io/v1
kind: ExternalSecret
metadata:
  name: forgejo-db-env
spec:
  refreshInterval: "15s"
  secretStoreRef:
    name: vault-backend-global
    kind: ClusterSecretStore
  target:
    name: forgejo-db-env
    creationPolicy: Owner
    template:
      type: Opaque
  data:
    - secretKey: FORGEJO__database__USER
      remoteRef:
        key: forgejo-secrets/forgejo-db-env
        property: FORGEJO__database__USER
    - secretKey: FORGEJO__database__PASSWD
      remoteRef:
        key: forgejo-secrets/forgejo-db-env
        property: FORGEJO__database__PASSWD

Persistent Storage

Two PVCs — one for the Forgejo config volume, one for all data (repos, LFS, avatars, etc.):

# apps/base/forgejo/storage-config.yaml
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: forgejo-config
  namespace: forgejo
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 1Gi

# apps/base/forgejo/storage-data.yaml
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: forgejo-data
  namespace: forgejo
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 4Gi

Adjust storage sizes to taste — 4Gi for data is a reasonable starting point for a small team, but bump it up if you’re storing large LFS assets.

Deployment

The deployment uses the rootless image variant, which means no root privileges inside the container. An init container handles the chown to get filesystem permissions right before the main container starts.

# apps/base/forgejo/deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app.kubernetes.io/component: server
    app.kubernetes.io/instance: forgejo
    app.kubernetes.io/name: forgejo
  name: forgejo
  namespace: forgejo
spec:
  replicas: 1
  selector:
    matchLabels:
      app: forgejo
  strategy:
    type: Recreate
  template:
    metadata:
      labels:
        app: forgejo
        app.kubernetes.io/component: server
        app.kubernetes.io/instance: forgejo
        app.kubernetes.io/name: forgejo
        policy-type: app
    spec:
      initContainers:
        - name: fix-permissions
          image: busybox:1.37
          command:
            - sh
            - -c
            - |
              chown -R 1000:1000 /etc/gitea
              chown -R 1000:1000 /data
          securityContext:
            runAsUser: 0
          volumeMounts:
            - mountPath: /etc/gitea
              name: forgejo-config
            - mountPath: /data
              name: forgejo-data
      containers:
        - name: forgejo
          image: data.forgejo.org/forgejo/forgejo:13.0.3-rootless
          env:
            - name: USER_UID
              value: "1000"
            - name: USER_GID
              value: "1000"
          envFrom:
            - configMapRef:
                name: forgejo-config
            - secretRef:
                name: forgejo-db-env
          ports:
            - containerPort: 3000
              name: http
            - containerPort: 2222
              name: ssh
          livenessProbe:
            httpGet:
              path: /api/healthz
              port: 3000
            initialDelaySeconds: 60
            periodSeconds: 30
            failureThreshold: 3
            timeoutSeconds: 5
          readinessProbe:
            httpGet:
              path: /api/healthz
              port: 3000
            initialDelaySeconds: 30
            periodSeconds: 10
            failureThreshold: 3
            timeoutSeconds: 5
          resources:
            limits:
              memory: 2Gi
            requests:
              cpu: 500m
              memory: 512Mi
          securityContext:
            allowPrivilegeEscalation: false
            capabilities:
              drop:
                - ALL
            runAsGroup: 1000
            runAsNonRoot: true
            runAsUser: 1000
            seccompProfile:
              type: RuntimeDefault
          volumeMounts:
            - mountPath: /etc/gitea
              name: forgejo-config
            - mountPath: /data
              name: forgejo-data
      restartPolicy: Always
      securityContext:
        fsGroup: 1000
      volumes:
        - name: forgejo-config
          persistentVolumeClaim:
            claimName: forgejo-config
        - name: forgejo-data
          persistentVolumeClaim:
            claimName: forgejo-data

Using strategy: Recreate is important here since both PVCs are ReadWriteOnce — you can’t have two pods mounting them simultaneously.

Services

An internal ClusterIP service for HTTP, and a LoadBalancer for SSH (so git clone over SSH works without going through the HTTP gateway):

# apps/base/forgejo/service-http.yaml
apiVersion: v1
kind: Service
metadata:
  name: forgejo-server
  namespace: forgejo
spec:
  type: ClusterIP
  selector:
    app: forgejo
  ports:
    - name: http
      port: 3000

# apps/base/forgejo/service-ssh.yaml
apiVersion: v1
kind: Service
metadata:
  name: forgejo-ssh
  namespace: forgejo
spec:
  type: LoadBalancer
  selector:
    app: forgejo
  ports:
    - name: ssh
      port: 2222
      targetPort: 2222

Base Kustomization

# apps/base/forgejo/kustomization.yaml
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
resources:
  - secret.yaml
  - configmap.yaml
  - storage-config.yaml
  - storage-data.yaml
  - deployment.yaml
  - service-http.yaml
  - service-ssh.yaml

Step 4: Ingress with Gateway API and TLS

I’m using Cilium’s Gateway API implementation rather than a traditional Ingress controller. First, provision a TLS certificate with cert-manager:

# apps/athena/forgejo/certificate.yaml
apiVersion: cert-manager.io/v1
kind: Certificate
metadata:
  name: forgejo-uclab-tls
  namespace: forgejo
spec:
  secretName: forgejo-uclab-tls
  issuerRef:
    name: letsencrypt-production
    kind: ClusterIssuer
  dnsNames:
    - forgejo.uclab.dev

Then create a Gateway that terminates TLS:

# apps/athena/forgejo/gateway.yaml
apiVersion: gateway.networking.k8s.io/v1
kind: Gateway
metadata:
  name: forgejo
  namespace: forgejo
  annotations:
    cert-manager.io/cluster-issuer: letsencrypt-production
spec:
  gatewayClassName: cilium
  listeners:
    - hostname: forgejo.uclab.dev
      name: forgejo-uclab-dev-http
      port: 80
      protocol: HTTP
    - hostname: forgejo.uclab.dev
      name: forgejo-uclab-dev-https
      port: 443
      protocol: HTTPS
      tls:
        mode: Terminate
        certificateRefs:
          - kind: Secret
            name: forgejo-uclab-tls
      allowedRoutes:
        namespaces:
          from: All

And an HTTPRoute to forward traffic to the Forgejo service:

# apps/athena/forgejo/httproute.yaml
apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: forgejo
  namespace: forgejo
spec:
  hostnames:
    - forgejo.uclab.dev
  parentRefs:
    - name: forgejo
  rules:
    - backendRefs:
        - name: forgejo-server
          port: 3000
      matches:
        - path:
            type: PathPrefix
            value: /

Overlay Kustomization

The cluster-specific overlay (I call mine athena) pulls in the base and adds the gateway resources:

# apps/athena/forgejo/kustomization.yaml
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
namespace: forgejo
resources:
  - ../../base/forgejo/
  - gateway.yaml
  - httproute.yaml
  - certificate.yaml

Deployment Order

When applying this for the first time, order matters:

Apply the database layer first (databases/base/forgejo/) and wait for the CNPG cluster to be ready and the forgejo-db-rw service to exist.
Apply the app layer (apps/athena/forgejo/).

With FluxCD or ArgoCD you can express this as a dependency, but if you’re applying manually just give the DB a minute or two to initialize.

kubectl apply -k databases/base/forgejo/
kubectl wait --for=condition=Ready cluster/forgejo-db -n forgejo --timeout=120s
kubectl apply -k apps/athena/forgejo/

Verifying the Deployment

# Check that all pods are running
kubectl get pods -n forgejo

# Check the CNPG cluster status
kubectl get cluster forgejo-db -n forgejo

# Tail Forgejo logs
kubectl logs -n forgejo -l app=forgejo -f

# Check that a backup ran
kubectl get backup -n forgejo

Once everything is up, navigate to https://forgejo.uclab.dev and you should land directly on the Forgejo dashboard — no installer, since we set INSTALL_LOCK=true.

Restoring from Backup

If you ever need to restore, swap the bootstrap.initdb block in db.yaml for a recovery block:

bootstrap:
  recovery:
    database: forgejodb
    owner: forgejo
    source: source
    secret:
      name: forgejo-db-credentials

externalClusters:
  - name: source
    plugin:
      name: barman-cloud.cloudnative-pg.io
      parameters:
        barmanObjectName: forgejo-objectstore
        serverName: forgejo-db

CNPG will replay WAL archives from MinIO up to the latest available point, giving you near-zero RPO recovery.

Wrapping Up

This setup gives you a production-grade self-hosted Git service with:

Automatic PostgreSQL failover via CNPG’s two-instance cluster
Continuous WAL archiving and nightly base backups to S3
Automatic TLS certificate rotation via cert-manager
Proper rootless container security with a hardened securityContext
GitOps-friendly Kustomize overlays for managing multiple clusters

The main moving parts to swap out if you’re adapting this to your own environment are the secret store (Vault + ESO), the S3 backend (MinIO), and the ingress controller (Cilium Gateway API). Everything else is pretty standard Kubernetes.

my DevOps Odyssey

“Σα βγεις στον πηγαιμό για την Ιθάκη, να εύχεσαι να ‘ναι μακρύς ο δρόμος, γεμάτος περιπέτειες, γεμάτος γνώσεις.” - Kavafis’ Ithaka.

Deploying Forgejo on k3s with CloudNativePG and S3 Backups

2026-03-01

Series:lab

Categories:Kubernetes

Tags:#k3s, #forgejo, #cloudnative-pg, #gitops, #s3-backup, #lab

Forgejo on K3S:
