Key Insight: The Full Traffic Chain

Internet
   ↓
Ingress  (routes by hostname/path → service name + service port)
   ↓
Service  (port → targetPort)
   ↓
Pod/Container  (containerPort / what the process actually binds)

Each arrow is where a port number must match its neighbour. A mismatch at any link causes traffic to silently fail to route.

containerPort is Documentation Only

spec:
  containers:
    ports:
      - containerPort: 3005  # ← has NO effect on actual network behaviour

• This is purely informational — a hint for humans and tooling.
• Kubernetes does not use it to expose or map any port.
• The container listens on whatever port its process actually binds to.
• The container will still listen on its default port (e.g. 80) regardless of what containerPort says.

[!note] Edge case Some tools (e.g. kubectl port-forward) can use named ports defined here, but the field has zero effect on actual network routing.

Environment Variable PORT Actually Changes the Listening Port

# configMap
data:
  PORT: "3005"

• Setting PORT=3005 via a ConfigMap causes the container to actually listen on port 3005.
• Visible in the pod logs and verifiable via port-forwarding.
• ⚠️ This only works if the application is coded to respect the PORT environment variable.
  audiobookshelf supports this — many images do not.
• Works regardless of what value is set in containerPort.

Port Numbers Refer to the Container/Cluster Network — Not the Host

• In Docker Compose: HOST_PORT:CONTAINER_PORT — maps a port from the physical machine into the container.
• In Kubernetes: there is (almost) no host port. The single port number always refers to the container-side port.
• Exposure to the outside world is handled by Services and Ingress at a higher level.

[!note] Edge case: hostPort There is a hostPort field in the container spec that mimics Docker’s host-side mapping — but it is considered an anti-pattern in Kubernetes and almost never used.

Service Ports

apiVersion: v1
kind: Service
spec:
  ports:
    - port: 8080        # Port other pods in the cluster use to reach this Service
      targetPort: 3005  # Must match the containerPort (the actual listening port)
  selector:
    app: audiobookshelf  # Must match the pod's label

Important rules:

• targetPort and containerPort must match.
• If targetPort is omitted, Kubernetes uses the value of port — so in that case port must equal containerPort.
• Always set targetPort explicitly to avoid subtle bugs when values change.
• targetPort can also be a named port string (defined via name: in containerPort), which decouples the service from exact port numbers.

Ingress Port

apiVersion: networking.k8s.io/v1
kind: Ingress
spec:
  rules:
    - host: audiobookshelf.example.com
      http:
        paths:
          - backend:
              service:
                name: audiobookshelf-svc  # Must match Service name
                port:
                  number: 8080            # Must match Service's `port` field

• The port number here must match the port field in the corresponding Service (not targetPort, not containerPort).
• The service name must also match.

Summary: What Must Match What

Ingress backend port  ──►  Service port
                               │
                           targetPort  ──►  containerPort / actual process port
                                                    ▲
                                             set via env var PORT
                                             (if app supports it)

Practical Verification Steps

1. Check what port the container actually listens on → look at pod logs

2. Verify via port-forwarding:

   kubectl port-forward pod/<pod-name> 3005:3005
   # then curl localhost:3005


3. Describe the pod to see reported containerPort (remember: this may not reflect reality)
