Deploying NetBox on k3s

NetBox is the source of truth for network and infrastructure documentation. If you run a homelab or a small datacenter and want to know what IP belongs where, what VLANs exist, and which rack holds which server — NetBox is the tool for the job. This post walks through deploying it on a k3s cluster using the official Helm chart, FluxCD for GitOps, and HashiCorp Vault via ExternalSecrets for secret management.

netbox

Prerequisites

A working k3s cluster (this was tested on a Pi5/NUC mixed cluster)
FluxCD bootstrapped and managing your cluster
The external-secrets-operator installed and a ClusterSecretStore pointing at Vault
Vault with a KV v2 secrets engine enabled
Helm 3 (for inspection only — Flux handles the actual deployment)

Repository Layout

Everything lives under apps/base/netbox/:

apps/base/netbox/
├── helmrelease.yaml
├── helmrepo.yaml
├── kustomization.yaml
├── kustomizeconfig.yaml
├── namespace.yaml
├── secrets.yaml
└── values.yaml

Step 1: Namespace

# namespace.yaml
apiVersion: v1
kind: Namespace
metadata:
  name: netbox

Step 2: Helm Repository

The official NetBox chart lives at https://charts.netbox.oss.netboxlabs.com/ — not on Artifact Hub’s main index.

# helmrepo.yaml
apiVersion: source.toolkit.fluxcd.io/v1
kind: HelmRepository
metadata:
  name: netbox
  namespace: netbox
spec:
  url: https://charts.netbox.oss.netboxlabs.com/
  interval: 24h

Step 3: Helm Release

The chart is referenced by version and values are injected via a ConfigMap that kustomize generates from values.yaml. The kustomizeconfig.yaml wires the generated ConfigMap name hash into the valuesFrom reference automatically.

# helmrelease.yaml
apiVersion: helm.toolkit.fluxcd.io/v2
kind: HelmRelease
metadata:
  name: netbox
  namespace: netbox
spec:
  interval: 1h
  chart:
    spec:
      chart: netbox
      version: "8.0.23"
      sourceRef:
        kind: HelmRepository
        name: netbox
        namespace: netbox
      interval: 12h
  valuesFrom:
    - kind: ConfigMap
      name: netbox-values

# kustomizeconfig.yaml
nameReference:
  - kind: ConfigMap
    version: v1
    fieldSpecs:
      - path: spec/valuesFrom/name
        kind: HelmRelease

# kustomization.yaml
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
namespace: netbox
resources:
  - namespace.yaml
  - secrets.yaml
  - helmrepo.yaml
  - helmrelease.yaml

configMapGenerator:
  - name: netbox-values
    files:
      - values.yaml=values.yaml

configurations:
  - kustomizeconfig.yaml

Step 4: Vault Secrets

Store the following paths in Vault before anything else. The structure matters — the chart’s configuration script reads each secret by key name.

# Django secret key
vault kv put netbox/secretkey \
  secretKey="$(openssl rand -hex 50)"

# Superuser account
vault kv put netbox/superuser \
  username="admin" \
  email="[email protected]" \
  password="your-admin-password" \
  api_token="$(openssl rand -hex 20)"

# PostgreSQL
vault kv put netbox/postgresql \
  password="netbox-db-pass" \
  postgresPassword="postgres-superuser-pass"

# Redis (empty password is fine for internal-only)
vault kv put netbox/redis \
  password="redis-pass"

# Email/SMTP (empty string if not using)
vault kv put netbox/email \
  password="email-pass"

Step 5: ExternalSecrets

This is where most people hit a wall. The chart projects multiple Kubernetes secrets into a single volume, and each secret must have exactly the right key names. The way to find them is:

helm template netbox netbox/netbox --version 8.0.23 \
  | grep -A5 -B5 "superuser_password\|email_password\|db_password"

From that output, the chart maps secrets like this:

Kubernetes Secret	Key	Mounted/Used as
`netbox-secret`	`secret_key`	Django `SECRET_KEY`
`netbox-secret`	`email_password`	SMTP password
`netbox-superuser-secret`	`username`	env `SUPERUSER_NAME`
`netbox-superuser-secret`	`email`	env `SUPERUSER_EMAIL`
`netbox-superuser-secret`	`password`	`/run/secrets/superuser_password`
`netbox-superuser-secret`	`api_token`	`/run/secrets/superuser_api_token`
`netbox-postgresql-secret`	`password`	DB user password
`netbox-postgresql-secret`	`postgres-password`	Bitnami PG superuser

Note that email_password lives in netbox-secret, not in the superuser secret. This is counterintuitive and not documented clearly — it caught me out multiple times.

secrets.yaml

---

apiVersion: external-secrets.io/v1
kind: ExternalSecret
metadata:
  name: netbox-secret
spec:
  refreshInterval: "15s"
  secretStoreRef:
    name: vault-backend-global
    kind: ClusterSecretStore
  target:
    name: netbox-secret
    creationPolicy: Owner
  data:
    - secretKey: secret_key
      remoteRef:
        key: netbox/secretkey
        property: secretKey
    - secretKey: email_password
      remoteRef:
        key: netbox/email
        property: password
---

apiVersion: external-secrets.io/v1
kind: ExternalSecret
metadata:
  name: netbox-superuser-secret
spec:
  refreshInterval: "15s"
  secretStoreRef:
    name: vault-backend-global
    kind: ClusterSecretStore
  target:
    name: netbox-superuser-secret
    creationPolicy: Owner
  data:
    - secretKey: username
      remoteRef:
        key: netbox/superuser
        property: username
    - secretKey: email
      remoteRef:
        key: netbox/superuser
        property: email
    - secretKey: password
      remoteRef:
        key: netbox/superuser
        property: password
    - secretKey: api_token
      remoteRef:
        key: netbox/superuser
        property: api_token
---

apiVersion: external-secrets.io/v1
kind: ExternalSecret
metadata:
  name: netbox-postgresql-secret
spec:
  refreshInterval: "15s"
  secretStoreRef:
    name: vault-backend-global
    kind: ClusterSecretStore
  target:
    name: netbox-postgresql-secret
    creationPolicy: Owner
  data:
    - secretKey: password
      remoteRef:
        key: netbox/postgresql
        property: password
    - secretKey: postgres-password
      remoteRef:
        key: netbox/postgresql
        property: postgresPassword
---

apiVersion: external-secrets.io/v1
kind: ExternalSecret
metadata:
  name: netbox-redis-secret
spec:
  refreshInterval: "15s"
  secretStoreRef:
    name: vault-backend-global
    kind: ClusterSecretStore
  target:
    name: netbox-redis-secret
    creationPolicy: Owner
  data:
    - secretKey: redis-password
      remoteRef:
        key: netbox/redis
        property: password

Step 6: Values

A few k3s-specific decisions here:

persistence.enabled: false — local-path is ReadWriteOnce and doesn’t support media file persistence across replicas. Re-enable this if you add Longhorn or NFS.
allowedHosts: ["*"] — fine for a homelab; restrict to your actual hostname in production.

values.yaml

superuser:
  existingSecret: netbox-superuser-secret

existingSecret: netbox-secret
existingSecretKey: secret_key

allowedHosts:

- "netbox.local"
- "netbox"
- "localhost"
- "*"

timeZone: Europe/Berlin
loginRequired: false
defaultLanguage: en-us

persistence:
  enabled: false

postgresql:
  enabled: true
  auth:
    username: netbox
    database: netbox
    existingSecret: netbox-postgresql-secret
    secretKeys:
      adminPasswordKey: postgres-password
      userPasswordKey: password
  primary:
    persistence:
      enabled: true
      storageClass: "local-path"
      size: 5Gi
    resources:
      requests:
        cpu: 100m
        memory: 256Mi
      limits:
        cpu: 500m
        memory: 512Mi

redis:
  enabled: true
  auth:
    existingSecret: netbox-redis-secret
    existingSecretPasswordKey: redis-password
  master:
    persistence:
      enabled: true
      storageClass: "local-path"
      size: 1Gi
    resources:
      requests:
        cpu: 50m
        memory: 64Mi
      limits:
        cpu: 200m
        memory: 128Mi

resources:
  requests:
    cpu: 100m
    memory: 512Mi
  limits:
    cpu: 1000m
    memory: 1Gi

worker:
  resources:
    requests:
      cpu: 50m
      memory: 256Mi
    limits:
      cpu: 500m
      memory: 512Mi

housekeeping:
  resources:
    requests:
      cpu: 50m
      memory: 128Mi
    limits:
      cpu: 200m
      memory: 256Mi

replicaCount: 1

Step 7: Deploy

Commit everything and push:

git add apps/base/netbox/
git commit -m "feat(netbox): initial deployment"
git push

Watch Flux reconcile:

flux reconcile kustomization apps --with-source
kubectl get pods -n netbox -w

First boot takes 2–5 minutes. PostgreSQL initializes, then NetBox runs migrations, then the superuser is created. You’ll see the worker pod restart a few times while waiting for migrations — that’s normal.

Verifying the Deployment

kubectl get pods -n netbox
# All should be Running/Ready

kubectl get externalsecret -n netbox
# All should show READY=True

kubectl get helmrelease -n netbox
# Should show READY=True and the chart version

Accessing the UI (without Ingress)

Before you wire up your ingress or DNS, port-forward directly:

kubectl port-forward -n netbox svc/netbox 8000:80

Open http://localhost:8000 and log in with the credentials from netbox/superuser in Vault.

Note: If you get a Django Bad Request (400), add "localhost" or "*" to allowedHosts in values.yaml. Django rejects requests from hosts not explicitly in the allowlist.
