Self-hosting Umami Analytics

I wanted to add visitor analytics to this blog without relying on Google Analytics or any third-party cloud service. Umami is a great fit — it’s open source, privacy-friendly, GDPR-compliant, and self-hostable. This post covers how I deployed it on my k3s cluster using Cilium Gateway API and Cloudflare Tunnels, and the one gotcha that had me debugging for longer than I’d like to admit.

Analytics

Stack

  • k3s — lightweight Kubernetes running on a Raspberry Pi 5 cluster
  • CloudNative PG (CNPG) — Postgres operator for the Umami database
  • Cloudflare Tunnels — for exposing services to the internet without opening ports
  • Umami 3.0.3 — the analytics server itself

Database

I use CloudNative PG to manage the Postgres cluster. Two instances for HA, with WAL archiving to an object store via the barman-cloud plugin.

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: umami-db
spec:
  instances: 2
  bootstrap:
    initdb:
      database: umami
      owner: umami
      secret:
        name: umami-db-creds
  storage:
    size: 5Gi
  plugins:
    - name: barman-cloud.cloudnative-pg.io
      isWALArchiver: true
      parameters:
        barmanObjectName: umami-objectstore
  monitoring:
    enablePodMonitor: true

CNPG automatically creates three services: umami-db-rw (read-write, primary), umami-db-ro (read-only replicas), and umami-db-r (round-robin). Umami connects to the primary via umami-db-rw.umami.svc.cluster.local.

Umami Deployment

The ConfigMap holds non-sensitive config. Note the two env vars at the bottom — TRACKER_SCRIPT_NAME and COLLECT_API_ENDPOINT — more on why these are critical in a moment.

apiVersion: v1
kind: ConfigMap
metadata:
  name: umami-config
data:
  DB_TYPE: "postgresdb"
  DB_HOST: "umami-db-rw.umami.svc.cluster.local"
  DB_PORT: "5432"
  DB_DATABASE: "umami"
  TRACKER_SCRIPT_NAME: "x.js"
  COLLECT_API_ENDPOINT: "/api/x"

The Deployment references both the ConfigMap and a Secret for database credentials. One neat trick: Kubernetes lets you compose environment variables from previously defined ones in the same pod spec, so DATABASE_URL is built dynamically from the individual DB_* vars:

deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: umami
spec:
  replicas: 1
  selector:
    matchLabels:
      app: umami
  template:
    metadata:
      labels:
        app: umami
    spec:
      containers:
        - name: umami
          image: ghcr.io/umami-software/umami:3.0.3
          ports:
            - containerPort: 3000
          env:
            - name: DB_TYPE
              valueFrom:
                configMapKeyRef:
                  name: umami-config
                  key: DB_TYPE
            - name: DB_HOST
              valueFrom:
                configMapKeyRef:
                  name: umami-config
                  key: DB_HOST
            - name: DB_PORT
              valueFrom:
                configMapKeyRef:
                  name: umami-config
                  key: DB_PORT
            - name: DB_DATABASE
              valueFrom:
                configMapKeyRef:
                  name: umami-config
                  key: DB_DATABASE
            - name: TRACKER_SCRIPT_NAME
              valueFrom:
                configMapKeyRef:
                  name: umami-config
                  key: TRACKER_SCRIPT_NAME
            - name: COLLECT_API_ENDPOINT
              valueFrom:
                configMapKeyRef:
                  name: umami-config
                  key: COLLECT_API_ENDPOINT
            - name: DB_USERNAME
              valueFrom:
                secretKeyRef:
                  name: umami-env-container-db
                  key: DB_USERNAME
            - name: DB_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: umami-env-container-db
                  key: DB_PASSWORD
            - name: DATABASE_URL
              value: "postgres://$(DB_USERNAME):$(DB_PASSWORD)@$(DB_HOST):$(DB_PORT)/$(DB_DATABASE)"
          resources:
            requests:
              cpu: 100m
              memory: 256Mi
            limits:
              cpu: 500m
              memory: 512Mi
          livenessProbe:
            httpGet:
              path: /api/heartbeat
              port: 3000
            initialDelaySeconds: 30
            periodSeconds: 15
          readinessProbe:
            httpGet:
              path: /api/heartbeat
              port: 3000
            initialDelaySeconds: 10
            periodSeconds: 10

And the Service:

apiVersion: v1
kind: Service
metadata:
  name: umami-server
  namespace: umami
spec:
  selector:
    app: umami
  ports:
    - port: 3000

Cloudflare Tunnel Config

The blog runs behind a Cloudflare Tunnel. The tunnel config is stored as a ConfigMap and consumed by a cloudflared Deployment. Traffic for umami.uclab.dev is routed directly to the Umami service by cluster DNS.

apiVersion: v1
kind: ConfigMap
metadata:
  name: cloudflared
data:
  config.yaml: |
    tunnel: uclab
    credentials-file: /etc/cloudflared/creds/credentials.json
    metrics: 0.0.0.0:2000
    no-autoupdate: true
    ingress:
    - hostname: uclab.dev
      service: http://uclab:80
    - hostname: umami.uclab.dev
      service: http://umami-server.umami.svc.cluster.local:3000

Tracking Script in Hugo

In layouts/partials/head.html:

<script
  defer
  src="https://umami.uclab.dev/x.js"
  data-website-id="YOUR_WEBSITE_ID">
</script>

The Gotcha: Ad Blockers

After deploying everything and verifying Umami was reachable, the dashboard still showed zero visitors. The culprit was Ghostery (and by extension any privacy-focused browser extension like uBlock Origin or Privacy Badger). These tools maintain blocklists that match common analytics script patterns — /script.js from a known analytics domain is a dead giveaway.

Umami’s documentation covers this cleanly. You can rename both the tracker script and the collection endpoint using environment variables:

  • TRACKER_SCRIPT_NAME — renames script.js to anything you want (e.g. x.js)
  • COLLECT_API_ENDPOINT — renames /api/send to anything you want (e.g. /api/x)

The tracker script automatically picks up the custom endpoint, so no additional data-api attribute is needed in the script tag. Setting these two env vars and redeploying was all it took. Ghostery no longer blocks the script because x.js from a custom domain doesn’t match any known analytics pattern.

This is also the approach recommended over proxying the script through your own domain — less infrastructure, same result.

Verification

With Ghostery enabled, open DevTools → Network tab and reload your blog. You should see:

  • x.js loading with status 200
  • A POST to /api/x firing immediately after with status 200

And within a minute, your Umami dashboard should start showing live visitors.
